Enterprise 1337R

SKU: 460068

  • 26 dBm max uplink

  • Up to 90 dB gain

  • 2 outdoor, 2 indoor N-type antenna ports

  • Remote monitoring and management

Check Mark Icon

3 Year Warranty

from Purchase

Design Icon

Tailored Solutions

Custom System Design

Location Icon

Assembled & Shipped

from a U.S. Facility


Product Description

Enterprise 1337R

The Enterprise 1337R is the newest C-band 5G repeater solution from WilsonPro. The enterprise-grade repeater is compatible with mid-band frequency 5G operating at 3.7 - 3.8 GHz. Sold as a repeater only, it’s an excellent upsell opportunity to upgrade existing WilsonPro 1300 and 4300 systems to support additional 5G coverage. With automatic TDD synchronization with the cellular network, it instantly amplifies C-band signal and requires no additional backhaul to extend 5G right away. The Enterprise 1337R offers additional flexibility with dual paths available for either a 2x2 MIMO or split mode setup. The repeater requires indoor and outdoor C-band antennas and 50-ohm coaxial cable with N-type connectors. Available with 50-ohm N-type connectors. Fits a standard (2U) rack. Carrier approval is required to turn on this repeater.

Warning Symbol

Warning: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

How it Works

Enterprise 1337R
1

The powerful antenna receives cellular signal and delivers it to the booster.

2

The booster amplifies the signal and serves as a relay between the cellular modem and the cell tower.

3

The cellular modem performs more efficiently as it feeds data to the booster and stays connected to the network.

Key Features

  • Automatic Time-Division Duplex (TDD) synchronization with cellular network

  • Requires no additional backhaul

  • Includes comprehensive network protection

  • Can be installed as a stand-alone repeater or in addition to any WilsonPro system

Specs

Model460068
Model Number460068
FrequenciesC Band 3.7 - 3.8 GHz
Max Gain90 dB
Max Uplink Power26 dBm
Max Downlink Power26 dBm
Impedance50 Ohms
Power110 - 240 V AC, 50 - 60 Hz, 30 W
ConnectorsN-Female
Amplifier Dimensions17.5 x 12 x 3.75 in
Amplifier Weight9.7 lbs
